Iron removal filter WATEX CMG10

Manufacturer: WATEX
Product code: CMG10
Combination does not exist
634.71
768.00

WATER QUALITY PROBLEM

When water gets in contacts with air, it changes the colour, turbidity increases and sediments appears. Water has a metallic taste. Water pipes are clogged and sanitation at the consumer becomes dirty. Suggested concentration of iron should be 0.1 mg/l and manganese 0.05mg/l.

SOLUTION

WATEX CMG series devices are effective drinking water treatment equipment, which reduces iron, manganese and turbidity in the water at the same time. It uses reagent (potassium permanganate) to remove iron. Despite the fact that the reagent is used, water can be used for drinking and other human life needs.

FILTER PERFORMANCE

WATEX CMG series equipment is based on a catalytic filtration media -"Greensand Plus" The filtration media is able to oxidize ferrous iron in the water and store it in the filter. To remove accumulated iron valve is automatically regenerated (rinsed). For regeneration KMnO4 is used. It restores the filtration media's ability to oxidize iron.

FILTER CONTROL

The equipment has an electronic CLACK WS1 (USA) controller with flow meter that controls the automatic regeneration (time control). The control valve all the information remains even if a power failure.





Show full description

Technical parameters of equipment

Unit

Model

CMG10

CMG12

CMG13

CMG14

Flow rate  Qnom

m3/h

1.0

1.5

2.0

2.6

The amount of water for regeneration

liters

280

410

480

560

Minimum flow rate for rinsing

m3/h

2.0

3.0

4.0

5.2

Tank size (diameter)

inches

10

12

13

14

m

0.25

0.30

0.33

0.37

Tank volume

liters

64

85

110

145

The amount of filtration media

liters

28.3

42.45

56.6

84.9

Dimensions











Length

m

0.25

0.30

0.33

0.37

Height

m

1.57

1.52

1.57

1.87

Water - drain connection

inches

1”

1”

1”

1 ¼”

Clack control valve



CI 1''

CI 1''

CI 1''

CI 1.25''

Filtration



Iron, manganese, turbidity, chromaticity

Tank material



FRP (fiberglass)

Filtration media



Greensand Plus, quarc sand 1x3mm, 3x5 mm

Operating pressure

bar

2-6

Electric Connection



220V, 50Hz, 1 phase

Electricity consumption

W

3 W



PRECONDITIONS

  • Sewer and electricity 220V connection
  • Input water pressure with a minimum pressure of 2.5 bar
  • Room temperature above 0° C
  • Water temperature to 25° C
  • Correct system installation

Additional equipment options:

  • Condensate isolation for tank;
  • By-pass valve – For easier assembly.


Width cm

Height cm

Length cm

Weight kg

30.00

160.00

55.00

80.00
