Show full descriptionGENERAL
|
Parameter |
Specification |
|
Inlet / Outlet |
1.5" Male BSPT or NPT |
|
Cycles |
Up to 9 |
|
Valve Material |
Glass filled composite |
|
Regeneration |
Downflow / Upflow |
CONTROL VALVE FLOW RATES
|
Parameter |
Specification |
|
Service @ 1 bar / 15 psi drop (includes meter) |
227 lpm (13.6 m³/h) (60 gpm) |
|
Backwash @ 1.7 bar / 25 psi drop |
163 lpm (9.8 m³/h) (43 gpm) |
OPERATING PRESSURES
|
Parameter |
Specification |
|
Minimum / Maximum |
1.4 – 8.6 bar (20 – 125 psi) |
OPERATING TEMPERATURES
|
Parameter |
Specification |
|
Minimum / Maximum |
4 – 43 °C (40 – 110 °F) |
DIMENSIONS & WEIGHT
|
Parameter |
Specification |
|
Distributor Pilot – 1.5" Female BSPT inlet & outlet |
50 mm OD |
|
Distributor Pilot – 1.5" Female NPT inlet & outlet |
1.90" OD (1.5" NPS) |
|
Drain Line Connection |
1" Male Elbow BSPT or NPT |
|
Brine Line Connection |
½" OD Poly Tube Compression |
|
Mounting Base |
4" – 8 UN |
|
Height from Top of Tank |
274 mm (10.75") |
|
Shipping Weight |
4.1 kg (9 lb) |
ELECTRICAL SPECIFICATIONS
|
Parameter |
Specification |
|
Supply Voltage – U.S. |
100–120 VAC |
|
Supply Voltage – International |
200–240 VAC |
|
Supply Frequency |
50/60 Hz |
|
Output Voltage |
15 VDC |
|
Output Current |
500 mA |
TANK APPLICATIONS
|
Parameter |
Specification |
|
Water Softener |
12" – 24" Diameter |
|
Water Filter |
12" – 24" Diameter |
CYCLES OF OPERATION
|
Parameter |
Specification |
|
Backwash |
1 – 120 minutes |
|
Rinse |
1 – 120 minutes |
|
Pause (service) |
1 – 480 minutes |
|
Brine (co-current) |
1 – 180 minutes |
|
Refill (softener) |
0.05 – 90.00 kg / 1 – 99 minutes |
|
Refill (filter) |
0.2 – 76.00 liters |
|
Width cm |
Height cm |
Length cm |
Weight kg |
|---|---|---|---|
|
38.50 |
33.00 |
44.50 |
9.00 |
Show full descriptionBy clicking the following links, you can view and download:
International Control Valve Fittings and Accessories Catalog.pdf
International Control Valve Service Parts.pdf
